The Story
The Mini-Coupler is 1" wide and fits from 1.65" OD to 2" OD Tube. The Mini-Coupler uses a 3/8″ × 3/4" long Grade 5 bolt with a Belleville washer and a Nyloc nut. The Mini-Coupler has a safe working load of 330 Pounds. (150 Kg)
Minimum Size
1.25" pipe, 1.66" OD pipe
Maximum Size
2" OD truss tube,1.5" pipe, 1.90" OD pipe
Working Load Limit
330 Pounds
Hardware
3/8″ × 3/4" long Grade 5 bolt with a Belleville washer and a Nyloc nut.
Weight
3 Pounds
What is a Cheeseboro? Cheeseborough clamps aka Cheeseboro, Scaffold Clamps, Couplers, Swivels and even Cheese-burger or Burger Clamps. The name is believed to derive from the Chesebro-Whitman manufacturing company of New York. The devices are used for connecting iron pipes or aluminum tubes. They come in two styles; rigid (aka fixed 90¡) or Swivel.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
The Mini-Coupler is 1" wide and fits from 1.65" OD to 2" OD Tube. The Mini-Coupler uses a 3/8″ × 3/4" long Grade 5 bolt with a Belleville washer and a Nyloc nut. The Mini-Coupler has a safe working load of 330 Pounds. (150 Kg)
Minimum Size
1.25" pipe, 1.66" OD pipe
Maximum Size
2" OD truss tube,1.5" pipe, 1.90" OD pipe
Working Load Limit
330 Pounds
Hardware
3/8″ × 3/4" long Grade 5 bolt with a Belleville washer and a Nyloc nut.
Weight
3 Pounds
What is a Cheeseboro? Cheeseborough clamps aka Cheeseboro, Scaffold Clamps, Couplers, Swivels and even Cheese-burger or Burger Clamps. The name is believed to derive from the Chesebro-Whitman manufacturing company of New York. The devices are used for connecting iron pipes or aluminum tubes. They come in two styles; rigid (aka fixed 90¡) or Swivel.
